Overview
- Bluetooth 2.0+EDR Class 1+
- Working distance 300m, up to 1000m using optional antenna
- USB 2.0 interface
- Bluetooth driver CD (Toshiba/BlueSoleil driver)
Bluetooth Adapter
$97.00
The Parani-UD100 is a class 1 type Bluetooth USB adapter that supports 300 meters of wireless transmission distance by default. The working distance can be further extended up to 1000 meters using optional replacement antenna. Thanks to its longer communication distance than other regular Bluetooth USB adapters, it is suitable for industrial or special applications.
Have a PQ Question? Ask Merlin™ — Free
Send it to askmerlin@powermonitors.com or text (540) 383-3144
Specs
Standards
Bluetooth 2.0+EDR Class 1USB 2.0
Max Transfer Rate
3 Mbps (EDR)
Frequency Range
2.402 ~ 2.480GHz
Transmit Output Power
+19dBm (+6dBm EDR) E.I.R.P
Receive Sensitivity
Basic 1Mbps: -88 dBmEDR 2Mbps: -87dBmEDR 3Mbps: -82dBm
Antenna Connector
RP-SMA
Antenna Gain
Default Stub Antenna: 1 dBiOptional Dipole Antennas:3 dBi & 5 dBiOptional Patch Antenna: 9 dBi
Working Distance* (In Open Field)
Stub antenna ∝ Stub antenna: 300m
Dipole (3 dBi) ∝ Dipole (3 dBi) : 400m
Dipole (5 dBi) ∝ Dipole (5 dBi): 600m
Patch antenna ∝ Patch antenna: 1km
*Working distance can vary depending on install environment.
Bluetooth Stack Software
Latest Device Driver: Toshiba / BlueSoleil
Bluetooth Profiles
DUN, FAX, SPP, HID, FTP, OPP, A2DP, AVRCP, HSP, HFP, PAN, BPP
Computer OS Support
Windows XP/Vista/7 (32/64bit)Linux (3rd party driver required)MAC OS X (MAC OS X driver required)
Size
72(L) x 22(W) x 10(H) mm
Operating Temperature
-20 ~ +70°C
Storage Temperature
-40 ~ +85°C
Humidity
90% Non-condensing
Regulatory Approvals
FCC, CE, TELEC, KCC, IC, Bluetooth SIG
Warranty
1 year Limited Warranty
