Revolution Mounting Clip & Bracket

Fast, Flexible Mounting for Your PMI Revolution Recorder

The Revolution Mounting Clip (also called the Revolution Mounting Bracket) is a custom-designed accessory that holds your PMI Revolution power quality recorder securely in the field, no matter where the job takes you. Because it’s built specifically for the Revolution’s enclosure, it fits perfectly every time — no improvised hardware, no zip-tying the recorder itself.

Three ways to mount, one accessory:

Magnetic — four embedded rare-earth magnets snap the Revolution onto any ferrous surface, like a meter cabinet, panel door, or enclosure wall, for tool-free installs and quick relocations.
Screw-mount — fasten the bracket permanently for long-term or high-vibration installations.
Zip tie — secure the Revolution to poles, conduit, cross-arms, or other round surfaces where screws and magnets won’t reach.

Whether you’re investigating an intermittent power quality issue, deploying a recorder for a short-term study, or setting up a permanent monitoring point, the Revolution Mounting Clip lets you position the recorder exactly where you need it in seconds. A built-in viewing window lets you read the recorder’s serial number and modem ESN without removing the bracket, and the recorder snaps out of the bracket independently, so you can pull the unit without unmounting the bracket itself.

Compatibility — designed for the PMI Revolution and 3-Phase Boomerang recorders. Made from a flame-retardant, UL-rated ABS/polycarbonate blend suitable for indoor or outdoor use, and measures 7.50″ L x 3.50″ W x 2.15″ H. The back is covered with a slip-resistant material to help the bracket stay in place when mounted magnetically to a vertical surface.
